The GE Druck DPI842 measures or sources Hz, kHz, CPM, CPH and pulses. It is the ideal instrument for process technicians and electronic engineers, providing a highly accurate calibration standard and versatile test tool. Dedicated features facilitate test and maintenance of electronic circuits and frequency instruments including frequency meters, batch counters, tachometers, motion pickups, integrators and flowmeters.

The DPI 842 features an automatic trigger that detects the best value regardless of waveform or amplitude. Frequency scaling reads in process units, e.g. flow or revolutions/minute. Programmable step and ramp outputs simplify calibration and diagnostics, while an adjustable "nudge" value provides an incremental output for setting switches, relays, trips, and alarms. In addition, an automatic switch test captures open/closed trip values, providing a fast and highly accurate "safety system" check. Its HART resistor can be switched into the loop when required by a HART digital communicator, avoiding the inconvenience of carrying a 250 ohm resistor. The DPI 842 is compatible with Intelligent Digital Output Sensor (IDOS) Universal Pressure Modules, allowing for total flexibility in pressure types and ranges.

Product Features:

• Measure or source 0.01 Hz to 50 kHz
• CPM, CPH and totalizing counter
• Generator with three output waveforms (sine, square and triangular) from 0.1 V to 24 V amplitude
• Dual readings provide simultaneous frequency output and mA measurement for transmitter and loop maintenance
• 24V loop power supply energizes transmitters and control loops
• Automatic switch test captures open/closed trip values to provide fast checks on safety systems
• HART loop resistor can be switched into the loop when required by a HART digital communicator
• Compatible with IDOS Pressure Modules (sold separately) for convenient measurements from 10 inH2O to 10,000 psi
• Advanced functions include hold, maximum/minimum/average, scaling, tare, and damping filter
• Large backlit display with menu driven interface
• Robust, weatherproof construction resists impact
• Secure grip and compact size for one-handed operation
• Applications
• Electronic test and maintenance
• Transmitter calibration and switch test
• Loop set-up and diagnostics

Included ;

1 - Frequency Loop Calibrator (DPI 842)

1 - Set of Batteries

1 - Calibration Certificate

1 - User Guide

1 - Set of Test Leads
