A lot of Testing Power in the hands of Electrical Installation Professionals!

DISPLAY

Color LCD 3.5 inches dot matrix.

ATT

Anti-Trip Technology (with 2 & 3 wire) for no trip LOOP L-PE testing on all RCDs.

With 2 wire only, very useful in case of no Neutral (i.e. 3-phase motor lines).

LOOP

・High test current range of 2Ω with 0.001Ω resolution.

・Zs Limit compares the values required by Electrical Installations Standard with measured results.

RCD

・Type AC, A, F, B(General & Selective), EV and Variable RCDs.

・Single and Auto test, Ramp test and Contact voltage.

EARTH

Earth resistance test 2 and 3 wires with all accessories included.

INSULATION

Resistance test 100, 250, 500 & 1000V with auto discharge voltage.

CONTINUITY

Continuity test at 200mA or 15mA with selectable buzzer for fast judgment.

PHASE ROTATION

On 3-phase lines with clear indication of the sequence on the display.

VOLTS

TRMS Voltage measurements 2 to 600V, Mains Frequency.

HELP

Display shows how to connect the instrument according to the function selected.

SPD

Surge Protection Device test, for SPD that uses varistor.

PAT

Portable Appliance Tester function, for Insulation and Protective conductor resistance test

Bluetooth

Communication by "KEW CONNECT"

SAFETY

IEC 61010-1 CAT Ⅳ 300V / CAT Ⅲ 600V, IEC 61557-1,2,3,4,5,6,7,10.
