FEATURES

• 3½ digit, high contrast LCD, with a maximum display of 1999
• Automatic polarity indication, zero adjustment
• Low battery (BAT) indication
• Over range indication: highest digit of (1) or (-1)
• EN 61010-1 CAT III 600V, EN 61326-1

ANALOG DISPLAY

• Large 90º wide and 84mm long mirror scale. (adapted to digital, analogue maximum indication 2400)
• Shock and vibration resistant TAUT BAND movement
• Pointer can be selected to either left-hand zero (normal mode) or center zero (galvo-mode)
• In galvo-mode pointer deflects right to indicate positive polarity and left to indicate negative polarity
• Automatic center zero and ohm zero
• Dimensions: 175(L) × 109(W) × 44(D)mm

SPECIFICATIONS

DC Voltage

Input impedance : 10MΩ

AC Voltage

․Input impedance : 10MΩ

DC Current

AC Current

Resistance

Capacitance

Instant Continuity

Frequency
