FEATURES

• Protection class: IP65
• 2 ranges for selection ( 2 function buttons )
• LOW : 50V~1.5kV
• Press the LOW button, 277 HP is ready for low voltage detection.
• HIGH : 1.5kV~132kV
• Press the HIGH button, 277 HP is ready for high voltage detection.
• Power consumption:
• Off : Less than 5uA
• Low voltage detection mode: Less than 40mA
• High voltage detection mode: Less than 40mA
• Circuit test function
• Press the Test button to make sure the whole circuit is working well
• before testing actual high voltage circuits.
• Optional accessory:
• HS-175 Telescopic hot stick (triangle-type)
• HS-120 Hot stick

SPECIFICATIONS
