FEATURES

Microprocessor-controlled.
2 ×16 characters; large intelligent LCD module.
20 Insulation test voltages 500V, 1kV, 1.5kV, 2kV, 2.5kV, 3kV, 3.5kV, 4kV, 4.5kV, 5kV, 5.5kV, 6kV, 6.5kV, 7kV, 7.5kV, 8kV, 8.5kV, 9kV, 9.5kV, 10kV.
Ener-Save™ feature to extend battery life.
Bargraph indicates test voltage; rise and decay can be observed.
Visual and audible warning if external voltage is present(>500Vac or Vdc.)
Insulation resistance; auto-ranging on all ranges.
Overload protection.
Low battery indicator (read time battery voltage measurement).
Measures insulation time duration of the test.
Low battery consumption.
Better than 10% accuracy on all ranges.
Auto-off.

Test voltage (DC V)	0.5kV to 10kV (0.5kV increment steps)
Measuring ranges (Auto-Ranges)	25GΩ / 0.5kV 25GΩ at 0.5kV → 500GΩ at 10kV
Accuracy	± 3% rdg ± 1 dgt
Output power limit	50uA to 100uA (1W)
Live warning	> 500V AC
Operation temperature	0°C to 40°C
Operation-humidity	85% Max. relative humidity
Dimensions	330(L) × 260(W) × 160(D)mm
Weight (battery included)	Approx. 3600g
Power source	1.5V “C”× 8 Alkaline batteries
Safety standard	EN 61010-1 CAT III 300V EN 61326-1
