FEATURES

• 11000-count LCD
• Easy to carry and easy to use
• Compact and lightweight
• Four terminal measurement for milliohm
• Measuring ranges :
•  1100.0 mΩ in steps of 100 µΩ
•  11000 mΩ in steps of 1 mΩ
• Measures down to 100 µΩ ( 0.1 mΩ )
• Large LCD indication ( 74 x 45 mm viewing area )
• Testing current :
•  1100.0 mΩ : 100 mA approx.
•  11000 mΩ : 10 mA approx.
• Data hold function
• Power source : 1.5V AA Alkaline battery x 6
• Low battery indicatio
• Protection fuse : 200mA / 250V x 1
• Operation temperature : 0 ~ 40°C
• Relative humidity : 80% max

SPECIFICATIONS

mΩ measurement (4-wire method)
