FEATURES

Microprocessor-controlled.
2 ×16 characters; large intelligent LCD module.
20 Insulation test voltages 500V, 1kV, 1.5kV, 2kV, 2.5kV, 3kV, 3.5kV, 4kV, 4.5kV, 5kV, 5.5kV, 6kV, 6.5kV, 7kV, 7.5kV, 8kV, 8.5kV, 9kV, 9.5kV, 10kV.
Ener-Save™ feature to extend battery life.
Bar-graph indicates test voltage; rise and decay can be observed.
Visual and audible warning if external voltage is present (>500Vac or Vdc.)
Insulation resistance; auto-ranging on all ranges.
Overload protection.
Low battery indicator (read time battery voltage measurement).
Measures insulation time duration of the test.
Low battery consumption.
Better than 10% accuracy on all ranges.
Auto-off.
Calculates Dielectric Absorption Ratio (DAR) automatically.
Calculates Polarization Index (PI) automatically.

Test voltage	From 500Vdc to 10kVdc Adjustable in 500V steps
Preset buttons	1kV / 2.5kV / 5kV / 10kV
Measuring ranges	800kΩ-500GΩ (auto-ranging)
Accuracy	± 5% ± 2 digits
Output power limit	1W
Voltage regulation	Selected voltage +20%-5% of nominal value unless current limited. Meaning that if output current is too high, the voltage will be lowered automatically.
Dimensions	330(L) × 260(W) × 160(D)mm
Weight (battery included)	Approx. 3600g
Power source	1.5V “C”× 8 Alkaline batteries
Safety standard	EN 61010-1 CAT III 300V EN 61326-1
