FEATURES

• Maximum testing current of 10A
• Ranges:
• 200.0μΩ / 2000μΩ 10A
• 20.00mΩ / 200.0mΩ 1A
• 2.000Ω / 20.00Ω 100mA
• 200.0Ω 10mA
• Maximum resolution of 0.1μΩ at 10A
• Four terminal measurements
• 4 Lines × 20 Characters LCD
• Optical USB to RS-232 data transmission
• Well isolated from contact
• 2 built-in optical LEDs for data transfer
• Memory function (200 measurement results)
• Auto power off
• Low battery indication
• Power source: Rechargeable battery DC14.8V 5200mAh 76.96Wh
• Safety Standard:
• IEC/EN 61010-1 CAT III 300V
• EN 61326-1

SPECIFICATIONS

4-wire method measurement

General
